Multiplex Soda Dispenser

Multiplex Soda Dispenser
TWBEVERAGE Post multiplex soda dispenser - Tower Unit beverage system due to the simple, fashion show shape and powerful functions, is widely used in cinemas, bars and other large high-end places.
INQUIRE

PRODUCTS OVERVIEW




TWBEVERAGE Post multiplex soda dispenser



                        Multiplex Soda Dispenser

Tower Unit beverage system for BIB concentrate, rapid cooling of mixed carbonated/non-carbonated beverages equipment system. The multiplex soda dispenser is equipped with BIB slurry feeding system, water cooling system, carbonization system and water circulation system. The BIB slurry system is powered by 40psi CO2 gas to pump the concentrated liquid into the facility and cooled by the water cooling system. The carbonization system carbonized the cooled direct drinking water with 80psi food-grade carbon dioxide gas, and mixed the carbonated water with the concentrated solution in a certain proportion after the production. The water circulation system ensures the temperature of the liquid in the pipeline, especially the exposed part between the tower head and the main engine, to ensure the taste of the product.



Multiplex Soda Dispenser Features:



☛ Can be customized: carbonated drinks, non-carbonated drinks, soda water, ice water, etc.;
☛ The built-in water cooling system and water circulation system can effectively ensure the     temperature and taste of the product
☛ The shape is simple, enhances the image, and does not take up space on the table;
☛ Can be matched with different installation tables and layouts, and the space is limited;

☛ It tastes better when you drink it at the moment.


Multiplex Soda Dispenser

Multiplex Soda Dispenser


Multiplex Soda Dispenser Parameters:

TOWER:

Model:TW-FT**-*F
Voltage:220V; 50/60HZ(Optional 110V)
Chiller Size:420*650*780mm (W*D*H)
Dispense:Carbonated/non-carbonated/soda water/ice water
                     can be customized according to the number of valve heads
Chiller Power:390W


CHILLER:

Temperature range:1-10℃
Refrigerant:R134a
Cooled capacity:4*500ml/min



TWBEVERAGE Post Multiplex Soda Dispenser :
Tower Unit beverage system due to the simple, fashion show shape and powerful functions, is widely used in cinemas, bars and other large high-end places.
